Hydraulic Pipe Bending Machine

Your Professional Hydraulic Pipe Bending Machine Supplier

Jiangsu Lifu Machinery Technology Co., Ltd. is headquartered in Zhangjiagang Precision Electromechanical Industrial Park, and its branch is located in Huashi Town, Jiangyin. The company is mainly engaged in the research and development, production, sales, and service of high-end metal pipe forming automation equipment. All key components on the processing equipment are processed using CNC machine tools. The company has multiple advanced CNC processing equipment, including large polyhedral horizontal machining centers, gantry machining centers, vertical machining centers, and slow wire walking, to ensure the stability and accuracy of the products.

Why Choose Us

01/

Our Certifications
Company has introduced a complete set of European and American technologies, CE standards, and completed ISO9001 certification in China. It is a professional manufacturer dedicated to providing comprehensive industrial automation equipment solutions for the pipeline industry.

02/

Production Equipment
The company has multiple advanced CNC processing equipment, including large polyhedral horizontal machining centers, gantry machining centers, vertical machining centers, and slow wire walking.

03/

Product Application
The company's products have successfully entered the production lines of well-known enterprises in industries such as automotive parts, aerospace, shipbuilding, motorcycles, furniture, air conditioning and refrigeration, and have received unanimous recognition from customers.

04/

Production Market
With the unremitting efforts of all employees and the trust and strong support of customers at home and abroad, Jiangsu Lifu Machinery has marketed its products to more than ten countries and regions including China, Russia, India, Southeast Asia, Japan, Mexico, South Africa, Iran, Brazil, Latin America, and more.

First 12 Last

Product Specifications

Hydraulic power (ton)	10
Bending angle	90°c
Bending formers	3/8” - 1/2” - 3/4” - 1” - 1 1/4” - 1 1/2” - 2”
Length (mm)	590
Width (mm)	690
Height (mm)	820
Net weight (kg)	60

Technical Parameter

Name	Unit	Parameter
Mild steel round tube	mm	¢63*3
Stainless Steel	mm	¢63*2
Light alloy annealed round tube	mm	¢63*5
Mild steel square tube	mm	50502.5
Mild steel rectangular tube	mm	50452.5
Mild steel round solid bar	mm	¢25
Mild steel square solid bar	mm	20*20
Min. bending radius	mm	25
Max. Bending radius(Standard)	mm	300
Head overhang (on bending centre)	mm	600
Head height (on bending centre)	mm	580
Bending centre height (from floor)	mm	1060
Max. bar passage inside the P.O.B. positionner	mm	50
Clamping adjustable stroke	mm	0-136
Shouldering adjustable stroke	mm	300
Mandrel retraction adjustable stroke	mm	0-136
Max. Bending Angle	°	190°
Through Effective Distance	mm	4000
Bending Speed(Max.)	°/sec	30
Max. rotation speed (axis Z)	°/sec	160
Max. shifting speed (axis X.)	mm/sec	800
Bending angle Precision	°	±0.10
Rotation angle Precision - axis Z	°	±0.10
Shifting Precision - axis X	mm	±0.10
Rotation Servo Motor Power	KW	1
Feeding Servo Motor Power	KW	1
System Motor Power	KW	5.5
Hydraulic Pump Volume	L	19
Max. Pressure	Mpa	16
*LWH (Packaging Dimension)*	mm	450012001350
Machine Weight	T	ABOUT 3.0

Types of Hydraulic Pipe Bending Machine

01/

Manual hydraulic pipe bender: This pipe bender through a manual pump to inject hydraulic oil into the hydraulic cylinder, push the piston rod to make the pipe bending mold contraction, so that the pipe will be bent into the desired shape. Manual hydraulic pipe bender is easy to operate, suitable for small-scale processing needs.

02/

Electro-hydraulic pipe bender: Electro-hydraulic pipe bender is usually driven by an electric pump, the operation is more convenient and efficient.

03/

CNC pipe bender: This bender combined with CNC technology, can be automated by a preset program, suitable for mass production and precision processing needs.

04/

Horizontal hydraulic pipe bender: Horizontal design makes the operation more convenient, suitable for a variety of pipe bending process.

05/

Multifunctional rolling pipe bender: This bender has a variety of functions, can be adapted to different processing needs, improve work efficiency.

06/

Digital display pipe bender: Digital display pipe bender through the digital display of operating parameters, to provide greater precision and controllability, suitable for higher precision requirements of processing tasks.

Application of Hydraulic Pipe Bending Machine

1. Piping: In the building piping system, it is used to bend water supply, drainage, heating and ventilation pipes to fit the layout and space requirements inside the building. Industrial piping systems, such as chemical plants, petroleum refineries, material handling pipelines, as well as power plants, steam piping and other bending processing.
2. Metal structure manufacturing: Manufacture of steel beams, columns and other components in steel structure buildings to meet specific structural design requirements. We provide bent metal parts for frames and support structures of large machinery.
3. Automobile manufacturing: Bending components such as automobile chassis, frames, and exhaust pipes to fit the overall design and spatial layout of the vehicle.
4. Furniture manufacturing: Bending metal tubing to create frame structures for chairs, tables and beds, adding aesthetic appeal and uniqueness to furniture.
5. Sports equipment manufacturing: For example, frame structures for fitness equipment and seat supports for stadiums.
6. Aerospace: Used to bend pipes such as oil and gas lines inside the fuselage of airplanes, as well as some structural parts.
7. Shipbuilding: Bending of structural components and various types of pipes of ships to meet the design and functional requirements of ships.
8. Solar equipment manufacturing: Bending tubes for solar racks to suit different installation angles and positions.

Certificate

productcate-1-1

FAQ

Q: What is a hydraulic pipe bender?

A: A hydraulic pipe bender is a device that uses hydraulic pressure to bend various metal pipes and conduit to specific angles.

Q: How to choose between a hydraulic and electric pipe bender?

A: The choice of a pipe bending machine depends on budget, use, and requirements. A hydraulic pipe bender is ideal for small-scale uses, where high precision and quality don't matter much.

Q: How does the hydraulic pressure affect the bending process in a hydraulic pipe and tube bender?

A: Hydraulic pressure in a hydraulic pipe and tube bender is used to exert force on the pipe or tube, gradually bending it into the desired shape. The pressure is generated by a hydraulic pump and transmitted to a piston or ram, which applies force at the bending point, allowing controlled and precise bending.

Q: How about the after-sales services?

A: After the sales are completed, we will provide online service and technical support if required.

Q: What are the typical applications or industries where hydraulic pipe and tube benders are used?

A: Hydraulic pipe and tube benders are commonly used in industries such as plumbing, automotive, HVAC (Heating, Ventilation, and Air Conditioning), construction, and manufacturing. They are utilized for bending pipes and tubes in applications ranging from pipe installations and repairs to creating custom-made tubing for various systems and structures.

Q: Did you provide any other accessories along with the machines?

A: Yes, we do provide accessories like a set of tools, decoiler, and transformer.

Q: What’s your payment term?

A: T/T or L/C, 30% as deposit, the balance need to be paid before delivery but after inspection.

Q: How about the delivery time?

A: Usually, it takes 30 working days for production.

Q: What is HS-Code of pipe bending machine?

A: The pipe bending machine HS-Code is 84622190; end forming machine HS-Code is 84629190; circular saw machine HS-Code is 84615000

Q: Do you provide all the operations and maintenance manuals in English？

A: Rich in overseas transaction experience, we have a full set of documentations, user manuals, assembly guidance all in ENGLISH.
You do not need to have any concern over language issues.

Q: Do you offer any after-sale services?

A: After finalizing the product, we clear up the production line and send you photos and videos for your assurance. In accord with your requests, we can also arrange for our experienced technicians and engineers to offer installation and training services.
Our customer services are also always active to answer any queries if required.

Q: How do you ensure quality of the machine before delivery？

A: To certify the excellent quality and precision of each component of the machine, we have gathered a diversity of qualified processing equipment and methods. Apart from the functioning of the machine, we also test each component of the machine before assembling it.
Our staff monitors each part with high-end technology and also full production line for almost 12 hours before delivering.

Q: How does the warranty work?

A: Machines are covered by a 2 year warranty from sale.
This warranty covers all manufacturing faults or defects. It does not cover the malfunctions or failures caused by your incorrect operations. The warranty is valid from the date of installation finish and machine normal working. During this period of warranty, if there is something wrong with the machine, we are responsible to provide project for solving this problem at the soonest, and help customers to restore production as soon as possible.

Q: Is there any video that we can see more details about the machine?

A: Yes, we update the video regularly.
https://www.lfpipe-bendingmachine.com/uploads/41968/video/home-video.mp4

Q: Can I come to your factory to observe pipe bending machines running?

A: On-site pipe bending machine running is available for observation should you book appointments with our sales representatives ( 1044463515@qq.com) and advise your itinerary at least 10 days before your visit.
We will arrange a pick-up from where you arrive in Shanghai to our factory

Q: What types of CNC tube bending services does your business offer?

A: We specialize in precision CNC tube bending machines for a variety of applications, including automobile, aerospace, construction, and custom projects etc. Our state-of-the-art CNC Tube benders and Lasertubes can handle tubes pipes of various sizes and materials.

Q: What precautions should be taken when using a hydraulic pipe bender?

A: Make sure that the saddle is fully threaded into the plunger fully hand tight. Make all hose connections between the cylinder and hydraulic pump. Make sure that the coupler(s) are fully hand tightened. Select the appropriate bending shoe for the pipe size.

Q: What are the objectives of hydraulic pipe bending machine?

A: These machines are useful in various applications such as manufacturing and automotive repair. They can be used for bending metal, aluminium, steel, and iron pipes. In addition to bending pipes, hydraulic pipe benders are also used for bending bars and other metal objects.

Q: What did I learn about the hydraulic pipe bender?

A: A hydraulic pipe bender is a device that uses hydraulic pressure to bend various metal pipes to specific angles. Hydraulic pipe benders work the same way as hydraulic car jacks and can perform multiple bends on the same pipe.

Q: What diameter can a hydraulic pipe bending machine bend the pipes up to?

A: Operation: Hand-operated hydraulic mechanism for precise and effortless bending. Pipe Size Range: Suitable for bending pipes ranging from 1/2 inch to 3 inches in diameter.

We're professional hydraulic pipe bending machine manufacturers and suppliers in China, specialized in providing high quality customized service. We warmly welcome you to buy bulk hydraulic pipe bending machine made in China here from our factory. For price consultation, contact us.
