Electric pipe bender is a kind of electric hydraulic machine, which is mainly used for bending and shrinking in pipe installation. Due to its wide range of applications, it is also called hydraulic pipe bender and manual pipe bender. This article briefly introduces the relevant content of electric pipe bender:
I. Product Overview:
1. Structural composition:
It is composed of electric motor (or diesel engine), reducer, transmission shaft, roller group, bracket and other components.
2. Working principle and working process (1) The motor drives the reducer to rotate through the coupling; (2) The output gear of the reducer meshes with the gear ring on the transmission shaft, so that the gear ratio of the two gears changes into an integer multiple relationship; (3) The speed n1 output by the motor is increased to a certain value through the speed increase box and then input into the feed port. At the same time, the motor output torque m1 is transmitted to the feed mechanism through the helical gear of the reducer; (4) The tool of the feed mechanism contacts the workpiece and generates a cutting force f1; (5) The workpiece is cut off from the mold under the action of the cutting force; (6) The cut blank is thrown into the rear discharge trough for discharge.
